SMX2000RMLV2U Specifications
APC Smart‑UPS X Line Interactive 2000 VA Rack/Tower Convertible (2U)
Manufacturer: APC by Schneider Electric
Manufacturer Model: SMX2000RMLV2U
Product Line: Smart‑UPS X
Product Series: 2000 VA Rack/Tower LCD, 100‑127 V
Product Type: Line Interactive UPS
Product Name: SMX2000RMLV2U 1920 VA / 1800 W UPS
KEY FEATURES:
Output Power Capacity: 1800 Watts / 1920 VA
Topology: Line Interactive, Pure Sine Wave Output
Rack/ Tower Convertible: 2U Rack‑mount or Tower form factor
Outlets: 3 × NEMA 5‑15R, 3 × NEMA 5‑20R, 1 × NEMA L5‑20R
SmartSlot: 1 slot for optional communication card
External Battery Capability: Supports up to 10 external battery packs (SMX120RMBP2U)
Automatic Voltage Regulation (AVR): Boost and Trim to correct under/over voltage
PERFORMANCE:
Efficiency at Full Load: ~98%
Transfer Time: ~2‑4 ms (4 ms typical; up to 8 ms maximum)
Waveform Type: Sine wave
Maximum Distortion: Less than 5% at full load
ENVIRONMENTAL & RELIABILITY:
Input Voltage Nominal: 120 V
Input Frequency: 50/60 Hz ±3 Hz (auto‑sensing)
Input Voltage Range: ~75‑154 V selectable
Recharge Time: ~3 hours
Designed for server/network equipment, data centers, and telecommunications racks
PHYSICAL:
Form Factor: 2U, 19‑inch rack/tower convertible
Dimensions (H×W×D): ~3.35″ × 17.01″ × 26.26″ (~85 mm × 432 mm × 667 mm)
Weight: ~84.77 lbs (~38.45 kg)
