QFX5210‑64C‑SAFI Specifications
Juniper QFX5210 64-Port QSFP+/QSFP28 Switch (Back-to-Front Airflow, SONiC Enabled)
Manufacturer: Juniper Networks
Manufacturer Model: QFX5210‑64C‑SAFI
Product Line: QFX Series Switches
Product Series: QFX5210 64C
Product Type: Fixed-configuration Data Center Ethernet Switch (SONiC)
Product Name: Juniper QFX5210‑64C‑SAFI Switch
KEY FEATURES:
Port Density: 64 QSFP+ or QSFP28 ports (supports breakout to 10 GbE, 25 GbE, 40 GbE, 50 GbE, 100 GbE)
Interface Speeds: 10 GbE, 25 GbE, 40 GbE, 50 GbE, 100 GbE via breakout cables
Airflow Orientation: Back-to-Front (“SAFI” variant)
Power Supplies: Dual AC hot-pluggable power supplies (redundant)
Software: SONiC enabled for disaggregated network environments
PERFORMANCE:
Switching Capacity (Bidirectional): Up to ~12.8 Tbps
Packet Forwarding Rate: Up to ~4.2 billion packets per second
Packet Buffer: ~42 MB
MAC Address Table: Up to ~264,000 entries
Jumbo Frame Support: Up to 9,216 bytes
ENVIRONMENTAL & RELIABILITY:
Designed for enterprise-scale data center leaf/spine fabrics and high-density deployments
Airflow Cooling Direction: Back-to-Front
Power Redundancy: Dual AC supplies in 1+1 configuration
Operating Temperature: 0 °C to 40 °C
Reliability: Enterprise-class design (MTBF not publicly listed)
PHYSICAL:
Form Factor: 2U Rack-Mount Chassis (fixed configuration)
Dimensions: Approx. 43.84 cm (W) × 8.77 cm (H) × 61.2 cm (D)
Weight: ~14.1 kg (~31.1 lbs)
