PWR-C3-750WDC-R= Cisco Systems 750W DC P/S at discount

PWR‑C3‑750WDC‑R Specifications

750 W DC Power Supply Module for Cisco Catalyst Series

Manufacturer: Cisco
Manufacturer Model: PWR‑C3‑750WDC‑R
Product Line: Cisco Catalyst Power Supplies
Product Series: 750 W DC Input Module (Config‑3)
Product Type: Hot‑swappable DC Power Supply
Product Name: Cisco 750 W DC Power Supply Module

KEY FEATURES:

Power Capacity: 750 Watts

Input Type: DC input (‑36 V to ‑72 V DC)

Cooling Orientation: Front‑to‑back airflow (denoted by “R”)

Configuration: Config‑3 power supply slot compatible

Hot‑Swap Support: Yes — field‑replaceable module

PERFORMANCE:

Maximum Output Power: 750 W
Cisco
+2
Router-Switch.com
+2

Input Current: ~25 A on DC input for full load
Cisco
+1

Output Rails: 12 V @ 62 A, 3.3 V @ 3 A
Cisco
+1

ENVIRONMENTAL & RELIABILITY:

Operating Temperature: –5 °C to 55 °C for DC power supply use in applicable chassis
Cisco

Storage Temperature: –40 °C to 70 °C
Cisco

Relative Humidity: Up to 95% non‑condensing (data‑centre grade)

Reliability Rating: Enterprise‑grade, suitable for 24×7 operation

PHYSICAL:

Form Factor: Module designed for insertion into compatible Cisco Catalyst chassis Config‑3 slot

Dimensions (H × D × W): 1.58 in × 2.15 in × 14.28 in (40.1 mm × 54.6 mm × 362.7 mm)
Cisco
+1

Weight: 3.7 lb (1.68 kg)
Cisco
+1

Airflow: Front‑to‑back (“R” variant) aligning with rack cooling design
