PWR-2700-AC= Cisco 2700 Watt Power supply at discount

PWR-2700-AC Specifications

2700 W AC Power Supply Module for select Cisco Catalyst chassis

Manufacturer: Cisco
Manufacturer Model: PWR-2700-AC
Product Line: Cisco Catalyst 6500/7600 Series Power Supplies
Product Series: 2700 W AC Power Module
Product Type: Hot‑swappable AC Power Supply
Product Name: Cisco 2700 W AC Power Supply Module

KEY FEATURES:

Power Capacity: 2700 Watts (nominal)

Input Type: AC, autoranging (typical 200‑240 VAC main for full rating)

Hot‑Swap Support: Yes — field‑replaceable in supported chassis

Compatibility: Designed for use in Cisco Catalyst 6500/7600 Series chassis (e.g., 7606)

Redundancy Support: Suitable for multi‑module redundant configurations

PERFORMANCE:

Maximum Output Power: 2700 W when operated at high‑line AC (200‑240 V)

Reduced Output at Low‑Line: ~1350 W when operated at lower AC line voltage (~100‑120 V)

AC Input Current: Up to ~16 A at 230 V for full output rating

Efficiency: High‑efficiency class suitable for enterprise switching chassis

ENVIRONMENTAL & RELIABILITY:

Operating Temperature: 0 °C to 40 °C

Storage Temperature: –40 °C to ~75 °C

Relative Humidity: Non‑condensing typical enterprise environment

Reliability: Enterprise/service‑provider grade, designed for continuous 24×7 operation

Form‑factor Note: Variant PWR‑2700‑AC is intended for the 7606 chassis; variant PWR‑2700‑AC/4 is for 7604 chassis and they are not interchangeable

PHYSICAL:

Form Factor: Plug‑in module for power‑supply bay in supported chassis

Mounting: Rear power bay insertion; supports tool‑less removal in redundant configurations

Weight: Approx. 8.4 kg (~18.5 lb)

Heat Dissipation: ~10,841 BTU/hour at full output
