PSM2-PTX-AC-R Juniper PTX High Capacity at discount

PSM2‑PTX‑AC‑R Specifications

Juniper High Capacity Single‑Phase AC Power Supply Module (Redundant)

Manufacturer: Juniper
Manufacturer Model: PSM2‑PTX‑AC‑R
Product Line: Juniper PTX Series Power Supply Modules (PSM)
Product Series: High Capacity AC PSM, Redundant Option
Product Type: Modular Power Supply Module (for PTX chassis)
Product Name: Juniper High Capacity AC PSM, Redundant – PSM2‑PTX‑AC‑R

KEY FEATURES:
Input Voltage: AC single‑phase (20 A or 30 A feeds)
Redundancy: Designed for redundant installation (R = Redundant)
Hot‑Pluggable / Hot‑Removable: Yes for chassis PSM slot usage
High Capacity: Enables up to eight PSMs per PDU in supported chassis
Supported Systems: Compatible with Juniper PTX3000 / PTX5000 series chassis high‑capacity AC PDU environment

PERFORMANCE:
Maximum Output Power (via associated PDU): ~23 kW with eight 20 A inputs or ~30.4 kW with eight 30 A inputs (single‑phase AC PDU context)
Operating Input Voltage Range: 200‑240 VAC line‑to‑line (for single‑phase high capacity AC PDU)
Operating Frequency: 50/60 Hz standard AC power systems

ENVIRONMENTAL & RELIABILITY:
Design: For enterprise service‑provider core router environments (24×7 operation)
Cooling & Airflow: Front‑to‑back airflow supported in chassis PDU/PSM module architecture
Fault Reporting & Monitoring: I²C‑bus protocol fault reporting and control supported in PDU/PSM system

PHYSICAL:
Form Factor: Module (PSM) designed to slide into PDU/PSM slot of PTX chassis
Dimensions & Weight: Platform‑specific; details specified in chassis documentation
Mounting: Intended for PTX Series chassis power module slots; hot‑swap capable
