OG CROSSHAIR VIII FORMULA ASUS AMD X570 AM4 Motherboard

CROSSHAIR VIII Specifications

ASUS ROG Crosshair VIII Hero (Wi-Fi) Motherboard

Manufacturer: ASUS
Manufacturer Model: CROSSHAIR VIII HERO
Product Line: ROG (Republic of Gamers)
Product Series: Crosshair VIII
Product Type: ATX Motherboard
Product Name: ASUS ROG Crosshair VIII Hero (Wi-Fi)

KEY FEATURES:
CPU Compatibility: AMD Ryzen 2nd and 3rd Gen, Ryzen 5000 Series (Zen 3)
Chipset: AMD X570
Form Factor: ATX
Memory Support: 4 × DDR4 DIMM slots, up to 128 GB, 2133–4800 MHz (OC)
Expansion Slots: 2 × PCIe 4.0 x16, 1 × PCIe 4.0 x16 (x4 mode), 1 × PCIe 4.0 x1
Storage Interface: 2 × M.2 slots (PCIe 4.0), 8 × SATA 6Gb/s
USB Ports: USB 3.2 Gen 2 (Type-A & Type-C), USB 3.2 Gen 1, USB 2.0
Networking: Intel I211-AT Gigabit LAN, Wi-Fi 6
Audio: ROG SupremeFX 7.1-channel HD audio
Features Supported: Aura Sync RGB, BIOS FlashBack, Robust VRM design, AI Overclocking

PERFORMANCE:
Maximum Data Transfer Rate: PCIe 4.0 x16 for GPU, PCIe 4.0 M.2 SSD support
Random Read IOPS: Not explicitly specified
Random Write IOPS: Not explicitly specified
Sequential Read Speed: Up to PCIe 4.0 speeds (approx. 7000 MB/s for M.2 SSDs)
Sequential Write Speed: Up to PCIe 4.0 speeds (approx. 5000 MB/s for M.2 SSDs)

ENVIRONMENTAL & RELIABILITY:
Operating Temperature Range: Not explicitly specified
Storage Temperature Range: Not explicitly specified
Operating Humidity: Not explicitly specified
Shock Resistance: Not explicitly specified
Vibration Resistance: Not explicitly specified
Durability: Military-grade components, robust heatsinks, active cooling for chipset

PHYSICAL:
Dimensions (W x D x H): ATX form factor
Weight: Not explicitly specified
Color: Black / Gray with ROG accents
