NIM-VAB-M Cisco 1-port with Annex M DSL modem at discount

NIM-VAB-M Specifications

Cisco Multimode VDSL2 / ADSL2/2+ NIM Module (Annex M)

Manufacturer: Cisco
Manufacturer Model: NIM-VAB-M
Product Line: Cisco Network Interface Module (NIM)
Product Series: DSL NIM (VDSL2 / ADSL)
Product Type: Interface Module for Router
Product Name: Cisco NIM-VAB-M

KEY FEATURES:

DSL Standards: VDSL2, ADSL, ADSL2, ADSL2+

Annex Support: Annex M

Interface Type: RJ-11 (POTS)

Modulation: Discrete Multi-Tone (DMT)

Vectoring: Supported

Bonding: 2-pair VDSL2 bonding supported

PERFORMANCE:

Maximum Data Rate (Downstream): Up to ~100 Mbps (VDSL2)

Maximum Data Rate (Upstream): Up to ~100 Mbps (VDSL2)

ADSL2+ Annex M Upstream: Enhanced upstream bandwidth

ENVIRONMENTAL & RELIABILITY:

Operating Temperature: 0 °C to 40 °C

Storage Temperature: –25 °C to 70 °C

Humidity: 10% to 90% non-condensing

MTBF: > 100,000 hours

COMPATIBILITY:

Supported Platforms: Cisco ISR 4000 Series

Supported IOS: Cisco IOS XE

Supported Profiles: VDSL2 profiles 8a/b/c/d, 12a/b, 17a, 30a; bonding; vectoring

PHYSICAL:

Dimensions: ~8.89 cm × 2.54 cm × 12.7 cm

Weight: ~181 g
