NFI-U05 Specifications

NFI 5-Port Unmanaged Industrial Ethernet Switch

Manufacturer: NFI
Manufacturer Model: NFI-U05
Product Line: NFI Industrial Switch Series
Product Series: U-Series
Product Type: Industrial Ethernet Switch (Layer 2 Unmanaged)
Product Name: NFI-U05 5-Port Unmanaged Industrial Switch

KEY FEATURES:
Ports: 5 × 10/100/1000 Mbps RJ45
Plug & Play: Yes, no configuration required
Auto-Negotiation: Yes, for speed and duplex
Auto-MDI/MDIX: Yes, eliminates need for crossover cables
DIN Rail Mountable: Yes
Operating Voltage: 12–48 V DC
Fanless Design: Silent operation

PERFORMANCE:
Switching Capacity: 10 Gbps
Forwarding Rate: 7.44 Mpps
MAC Address Table: 2K entries
Jumbo Frame Support: Up to 9 KB

ENVIRONMENTAL & RELIABILITY:
Operating Temperature: -40°C – 75°C
Storage Temperature: -40°C – 85°C
Humidity: 5% – 95% non-condensing
MTBF: ~500,000 hours
Shock & Vibration: IEC 60068-2 compliant

PHYSICAL:
Form Factor: DIN rail mountable
Typical Dimensions: 140 mm × 90 mm × 60 mm
Weight: ~0.8 kg
