MJA2500BH Specifications
Fujitsu MJA2500BH 500 GB 2.5‑inch SATA 3 Gb/s 5,400 RPM Hard Drive
KEY FEATURES
Storage Capacity: 500 GB
Interface Type: SATA 3 Gb/s (SATA II)
Form Factor: 2.5‑inch
Cache Memory: 8 MB
Recording Technology: Perpendicular Magnetic Recording (PMR)
Drive Type: Internal Hard Drive
Target Use: Notebook computers, external storage enclosures, and compact desktop systems
PERFORMANCE
Maximum Data Transfer Rate: 300 MB/s
Spindle Speed: 5,400 RPM
Average Seek Time: 12 ms (read), 14 ms (write)
Track-to-Track Seek Time: 1.5 ms
Average Latency: 5.56 ms
Optimized for general-purpose computing applications
PHYSICAL
Standard 2.5‑inch size
Height: 9.5 mm
Width: 70 mm
Depth: 100 mm
Weight: 101 g
RELIABILITY & ENVIRONMENTAL
Mean Time Between Failures (MTBF): 300,000 hours
Operating Temperature Range: 5°C to 55°C
Non-Operating Temperature Range: –40°C to 65°C
Operating Shock Resistance: 350 G (2 ms)
Non-Operating Shock Resistance: 900 G (1 ms)
Operating Vibration: 1.0 G at 5–20 Hz / 1.0 G at 20–300 Hz
Non-Operating Vibration: 2.0 G at 5–20 Hz / 5.0 G at 20–300 Hz
ADDITIONAL FEATURES
Hot-Swap Capable: No
Native Command Queuing (NCQ): Yes
Thermal Fly Height Control (TFC): Yes
Staggered Spin-up Technology: Yes
Whisper Quiet with Fluid Dynamic Bearing (FDB) Motors: Yes
RoHS Compliant: Yes
