L38488-001 HPE 2TB M.2 2280 PCIe 3×4 NVMe TLC SSD

L38488-001 Specifications

HPE 2TB M.2 2280 PCIe NVMe TLC SSD

Manufacturer: HPE
Manufacturer Model: L38488-001
Product Line: HPE / HP ZBook / HP Workstation
Product Type: Internal Solid State Drive
Product Name: HPE 2TB M.2 2280 PCIe NVMe TLC SSD

KEY FEATURES:
Storage Capacity: 2TB
Interface Type: PCI Express (PCIe) 3.0 x4 NVMe
Form Factor: M.2 2280
Drive Type: Internal
Flash Type: Triple-Level Cell (TLC) 3D NAND
Data Transfer Rate: Up to 3,500 MB/s (read), 3,000 MB/s (write)
Compatibility: Designed for HPE ZBook and HP Workstation systems supporting M.2 NVMe SSDs
Features Supported: High-performance NVMe interface, low latency, enterprise-class endurance

PERFORMANCE:
Maximum Data Transfer Rate: Up to 3,500 MB/s (read) / 3,000 MB/s (write)
Random Read IOPS: Up to 500,000 (4K QD32)
Random Write IOPS: Up to 480,000 (4K QD32)
Sequential Read Speed: Approximately 3,500 MB/s
Sequential Write Speed: Approximately 3,000 MB/s

ENVIRONMENTAL & RELIABILITY:
Operating Temperature Range: 0°C to 70°C (32°F to 158°F)
Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)
Operating Humidity: 5% to 95% (non-condensing)
Shock Resistance: 1,500 G / 0.5 ms
Vibration Resistance: 20 G peak (10–2,000 Hz)
MTBF (Mean Time Before Failure): 1.5 million hours
Endurance: Up to 1,200 TBW (Total Bytes Written)

PHYSICAL:
Dimensions (W × D × H): 22 mm × 80 mm × 2.3 mm (M.2 2280 standard)
Weight: Approximately 8 g
Color: Not explicitly specified
