FG-101E-BDL-950-36 Fortinet FortiGate 101E Network Security/Firewall

FG‑101E‑BDL‑950‑36 Specifications

Fortinet FortiGate 101E Next‑Generation Firewall – Bundle

Manufacturer: Fortinet
Manufacturer Model: FG‑101E‑BDL‑950‑36
Product Line: FortiGate
Product Series: 101E Series
Product Type: Network Security / Firewall Appliance (Bundle)
Product Name: FortiGate 101E Next‑Generation Firewall – Bundle

KEY FEATURES:
Firewall Throughput: 10 Gbps
IPsec VPN Throughput: 6 Gbps
NGFW Throughput: 2 Gbps
Threat Protection Throughput: 1.5 Gbps
Concurrent Sessions (TCP): 3 Million
New Sessions per Second (TCP): 300,000
Firewall Policies Supported: 8,000
Gateway-to-Gateway IPsec VPN Tunnels: 1,500
Client-to-Gateway IPsec VPN Tunnels: 1,500
SSL‑VPN Throughput: 600 Mbps
Concurrent SSL‑VPN Users (Recommended Maximum, Tunnel Mode): 500
Virtual Domains (Default / Maximum): 10 / 10
Maximum FortiSwitches Supported: 64
Maximum FortiAPs Supported: 128
Maximum FortiTokens Supported: 2,000
High Availability Support: Active/Active, Active/Passive
Network Interfaces: 12 × GE RJ45, 8 × SFP
USB Port: 2
Console Port (RJ45): 1
Wireless Interface: Not supported

PERFORMANCE:
Maximum Firewall Throughput: 10 Gbps
Maximum IPS Throughput: 4 Gbps
Maximum NGFW Throughput: 2 Gbps
Threat Protection Throughput: 1.5 Gbps
IPsec VPN Throughput: 6 Gbps
SSL‑VPN Throughput: 600 Mbps

ENVIRONMENTAL & RELIABILITY:
Operating Temperature Range: 0–40 °C (32–104 °F)
Storage Temperature Range: –35–70 °C (–31–158 °F)
Operating Humidity: 10–90% non‑condensing
Shock Resistance: Not explicitly specified
Vibration Resistance: Not explicitly specified
Noise Level: ~40 dBA

PHYSICAL:
Dimensions (W × D × H): 214 × 146 × 44 mm (8.4 × 5.7 × 1.73 inches)
Weight: ~3 kg (~6.6 lb)
Color: Not explicitly specified
Form Factor: Desktop / Rackmount convertible
Power Supply: Internal AC (100–240 V AC, 50–60 Hz)
Power Consumption (Average / Maximum): ~50 / 70 W
Heat Dissipation: ~239 BTU/h
