DELL WD22TB4 Specifications
Dell Thunderbolt 4 Dock – WD22TB4
Manufacturer: Dell
Manufacturer Model: WD22TB4
Product Line: Dell Thunderbolt Dock
Product Series: WD22TB4
Product Type: Thunderbolt 4 Docking Station
Product Name: Dell Thunderbolt 4 Dock WD22TB4
KEY FEATURES:
Docking Interface: Thunderbolt 4 (Type‑C connector)
Display Support: Up to 4 external displays (config dependent — dual 4K @ 60 Hz, up to triple QHD, etc.)
Video Outputs: 2 × DisplayPort 1.4, 1 × HDMI 2.0, 1 × USB‑C (DisplayPort 1.4 Alt Mode)
Thunderbolt Ports: 2 × Thunderbolt 4 USB‑C
USB Ports: 3 × USB‑A 3.2 Gen 1 (1 with PowerShare), 1 × USB‑C 3.2 Gen 2
Ethernet: Gigabit RJ‑45
Security Slots: Kensington lock slot, Noble Wedge lock slot
LED Indicators: Power adapter LED, power button LED, docking cable LED, RJ‑45 LEDs
Included Cable: ~0.8 m Thunderbolt 4 cable
Power Adapter: 180 W AC adapter included
PERFORMANCE:
Power Delivery: Up to 130 W to Dell laptops; up to 90 W to non‑Dell systems
Networking: Wired Gigabit Ethernet throughput for stable network connection
Display Modes: Support for high‑resolution display configurations including single 5K @ 60 Hz and multiple 4K displays
ENVIRONMENTAL & RELIABILITY:
Operating Systems Supported: Windows 10, Windows 11, Ubuntu 20.04 and later versions; Apple Thunderbolt systems supported with some limitations depending on host
Systems Management Features: Wake‑On‑LAN, PXE Boot, MAC address pass‑through, port disablement, etc.
Designed for enterprise and professional workstation environments with modular upgrade capability
PHYSICAL:
Form Factor: Compact Thunderbolt 4 dock with integrated cable
Typical Dimensions: 205 mm × 90 mm × 29 mm
Weight (without power adapter): ~650 g (1.43 lb)
Color: Black
