C9200-24PXG-1E Cisco Systems C9200 24-Port at discount

C9200-24PXG-1E Specifications

Cisco Catalyst 9200 Series 24‑Port Multi‑Gigabit PoE+ Managed Switch

Manufacturer: Cisco
Manufacturer Model: C9200-24PXG-1E
Product Line: Cisco Catalyst 9200 Series
Product Series: 24PXG
Product Type: Managed Access Switch
Product Name: Cisco Catalyst C9200‑24PXG 24‑Port Multi‑Gigabit PoE+ Switch

KEY FEATURES:
Port Configuration: 24 downlink ports with PoE+ (including multi‑gigabit support on part of the ports)
Multi‑Gig Support: Some ports support 2.5G/5G/10G speeds on copper (depending on exact variant)
PoE Budget: Up to 740W (with optional secondary power supply) in higher variants; smaller budgets (~370W) in base configurations
Modular Uplinks: Slots for modular uplink modules to connect to higher‑speed aggregation or core layers
Stacking: Supports StackWise 160 with stacking bandwidth up to ~160 Gbps
Software: Runs IOS XE with full Layer 2 and Layer 3 features, including static routing, OSPF, EIGRP, MACsec encryption
Security & Automation: AES‑128 MACsec encryption, NETCONF/RESTCONF/YANG support, SD‑Access ready

PERFORMANCE:
Switching Capacity: ~352 Gbps (for the base 24‑port model)
Forwarding Rate: ~261.9 Mpps
MAC Address Table: ~32,000 entries
Jumbo Frame Support: Up to ~9,198 bytes

ENVIRONMENTAL & RELIABILITY:
Operating Temperature Range: 0 °C to 45 °C
Storage Temperature Range: –40 °C to 70 °C
Operating Humidity: 5% to 90% non‑condensing
Field‑Replaceable Units (FRUs): Support for redundant power supplies and fans depending on configuration

PHYSICAL:
Dimensions (H × W × D): ~1.73″ × 17.5″ × 13.8″ (≈ 4.4 cm × 44.5 cm × 35.0 cm)
Weight: ~11.3 lb (~5.1 kg)
