ALTV2416ULCBI ALTRONIX 115VAC Power Supply at discount

ALTV2416ULCBI Specifications

Altronix 24 VAC 16‑Output CCTV Power Supply (Isolated PTC Protected Outputs)

Manufacturer: Altronix
Manufacturer Model: ALTV2416ULCBI
Product Line: ALTV2416UL Series
Product Series: ULCBI (Isolated PTC Protected)
Product Type: CCTV Power Supply / Distribution
Product Name: Altronix 24 VAC 16‑Output CCTV Power Supply (Isolated PTC Protected Outputs)

KEY FEATURES:
Input Voltage: 115 VAC, 50/60 Hz
Output Voltage: 24 VAC
Total Supply Current: 25 A (600 VA)
Number of Outputs: Sixteen (16) Class 2 Rated PTC protected auto‑resettable outputs
Maximum Output Per Device: 2.5 A per output
Surge Suppression: Included
Output Isolation: Yes, outputs isolated to minimize interference
LED Indicators: AC and DC status
Enclosure: Wall-mount indoor, ½″ & ¾″ combination knockouts

PERFORMANCE:
Output Capacity: 24 VAC @ 25 A continuous
Individual Output Capability: 2.5 A per output
BTU/Hr: Approx. 304 BTU/Hr

ENVIRONMENTAL & RELIABILITY:
Operating Temperature Range: 0 °C to 49 °C (32 °F to 120 °F)
Storage Temperature Range: –20 °C to 70 °C (–4 °F to 158 °F)
Relative Humidity: 85% ± 5%
UL Listed: Yes (UL 2044)
cUL Listed: Yes (CSA C22.2 No.1‑98)

PHYSICAL:
Dimensions (W x H x D): 13″ × 13.5″ × 3.25″ (330 mm × 343 mm × 83 mm)
Weight: Approx. 23.3 lb (10.568 kg)
Color: Not explicitly specified

COMPATIBILITY & COMPLIANCE:
Designed for powering CCTV cameras, heaters, and other video accessories requiring multiple isolated 24 VAC outputs
