AL400ULPD4 Specifications
Altronix 12/24VDC @ 4A UL Listed Power Supply
Manufacturer: Altronix
Manufacturer Model: AL400ULPD4
Product Line: Altronix Power Supplies
Product Series: AL Series
Product Type: Plug-in Power Supply / Charger
Product Name: AL400ULPD4 12/24VDC @ 4A Power Supply
KEY FEATURES:
Output Voltage: 12VDC or 24VDC selectable
Maximum Current: 4A
Input Voltage: 120VAC, 60Hz
UL Listed for safety
Built-in battery charger
Protected against overvoltage, overcurrent, and short-circuit
Suitable for access control, CCTV, and security systems
PERFORMANCE:
Total Power Output: 48W (12V x 4A) / 96W (24V x 4A)
Current Capacity: 4A maximum
Efficiency: High-efficiency switching power supply
ENVIRONMENTAL & RELIABILITY:
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature: -4°F to 140°F (-20°C to 60°C)
Humidity: 0%–90% non-condensing
Protection: Short circuit, overload, and thermal protection
Battery Backup: Supports sealed lead-acid batteries (up to 7AH typical)
PHYSICAL:
Enclosure: Metal chassis, plug-in style
Dimensions (W x D x H): 7.25″ x 6.5″ x 3.0″ (approx.)
Weight: 5.0 lbs (approx.)
Color: Gray
