9286CV-8ECC Lsi Logic SAS 8-Ports Adapter PCI-E at discount

9286CV‑8ECC Specifications

Broadcom / LSI Logic MegaRAID SAS 9286CV‑8ECC 8‑Port 6 Gb/s External SAS/SATA PCIe RAID Controller

Manufacturer: Broadcom / LSI Logic
Manufacturer Model: 9286CV‑8ECC
Product Line: MegaRAID SAS 9286 Series
Product Series: 9286CV‑8ECC
Product Type: PCIe RAID Controller / External SAS Controller
Product Name: Broadcom / LSI MegaRAID SAS 9286CV‑8ECC External RAID Controller

KEY FEATURES:

RAID Controller: Dual LSISAS2208 RAID on Chip (ROC) with two 800 MHz PowerPC cores

External Ports: 8 external SAS/SATA (6 Gb/s per port)

Connectors: 2 × Mini‑SAS external connectors (SFF‑8088)

Host Bus Interface: PCI Express 3.0 ×8

Cache Memory: 1 GB DDRIII SDRAM

Cache Protection: MegaRAID CacheVault Flash Cache Protection

RAID Levels Supported: 0, 1, 5, 6, 10, 50, 60

External JBOD Expansion: Supports up to hundreds of drives via SAS expanders

SSD Optimization: Includes CacheCade Pro 2.0 and Fast Path software ready

PERFORMANCE:

Data Transfer Rate: Up to 6 Gb/s per SAS/SATA port

Designed for enterprise external storage, high‑throughput RAID workloads

ENVIRONMENTAL & RELIABILITY:

Designed for enterprise server and storage array environments

Operating Temperature: Up to ~55 °C with CacheVault module

Operating Voltage: +3.3 V and +12 V

Mean Time Between Failures (MTBF): ~1,251,000+ hours

Enterprise RAID Protection Features: Online Capacity Expansion, Online RAID Level Migration, hot spares, load balancing, and more

PHYSICAL:

Form Factor: Low‑profile PCIe add‑in card (MD2 size)

Typical Dimensions: ~6.6″ × 2.536″

Platform Support: Wide OS support including Windows, Linux, Solaris, VMware, FreeBSD, etc
