6SK99AA#ABA HP Solid State Drive 1TB PCI Express

6SK99AA#ABA Specifications

HP 6SK99AA#ABA 1 TB TLC PCIe 3.0 x4 NVMe M.2 Solid State Drive

KEY FEATURES

Storage Capacity: 1 TB
Interface Type: PCIe 3.0 x4 NVMe
Form Factor: M.2 (2280)
Flash Type: Triple-Level Cell (TLC) NAND
Drive Type: Internal Solid State Drive
Target Use: HP Workstations, ZBook Mobile Workstations, and EliteBook Series Notebooks

PERFORMANCE

Sequential Read Speed: Up to 3,000 MB/s
Sequential Write Speed: Up to 2,000 MB/s
Random Read (4K): Up to 350,000 IOPS
Random Write (4K): Up to 300,000 IOPS
Latency: <0.05 ms typical
Optimized for high-speed data access, low latency, and reliability for workstation-class applications

PHYSICAL

Form Factor: M.2 Type 2280 (22 mm × 80 mm)
Thickness: 2.3 mm (typical)
Weight: ~8 g
Interface Connector: M-Key (PCIe NVMe)
Drive Type: Internal

RELIABILITY & ENVIRONMENTAL

Mean Time Between Failures (MTBF): 1.5 million hours
Endurance (TBW): 600 TB
Operating Temperature Range: 0 °C – 70 °C
Non-Operating Temperature Range: –40 °C – 85 °C
Shock Resistance: 1,500 G / 0.5 ms
Vibration Resistance (Operating): 2.17 G (7–800 Hz)
Vibration Resistance (Non-Operating): 3.13 G (7–800 Hz)

ADDITIONAL FEATURES

NVMe 1.3 Protocol Support: Yes
TRIM and S.M.A.R.T. Support: Yes
Dynamic Thermal Throttling: Yes
Power Loss Protection: Basic firmware-level
Low Power Consumption: Active: 4.5 W / Idle: <0.05 W
Compliance: RoHS, CE, FCC, WEEE
