656522-001 HP 400 Watts 5A Power Supply For Z1 at discount

656522-001 Specifications

HP 400 W ATX Power Supply for Z1 Workstation Series

Manufacturer: HP
Manufacturer Model: 656522-001
Product Line: HP Workstation Power Supply
Product Series: 400 W ATX for Z1 / Z1 G2 Workstations
Product Type: Internal Power Supply Unit
Product Name: HP 400 W Power Supply (Model 656522-001)

KEY FEATURES:
Power Capacity: 400 Watts
Input Voltage Range: 100–240 V AC / 5 A (at 100–240 V) / 4.5 A (at 118 V, 400 Hz)
Form Factor: ATX internal module designed for HP Z1 / Z1 G2 Workstation
Hot-Swap Support: No (standard internal PSU)
Connector Type: Standard ATX 20-Pin or 24-Pin (implementation dependent)

PERFORMANCE:
Rated Output Power: 400 W continuous
Example DC Output Rails (approximate): +12 V-B ~18 A; +12 V-CPU ~18 A; +11 VSB ~1.75 A

ENVIRONMENTAL & RELIABILITY:
Designed for enterprise-class workstation use with HP Z1 / Z1 G2 systems
Global AC input supports 100–240 V range for international compatibility

PHYSICAL:
Form Factor: Internal ATX power supply module
Typical Dimensions: Not specifically listed
Weight: Not specified
