506247-001 HP 500 Watts Switching Power Supply at discount

506247-001 Specifications

HPE 460W Common Slot Platinum Hot-Plug Power Supply Kit

Manufacturer: Hewlett Packard Enterprise (HPE)
Manufacturer Model: 506247-001
Product Line: HPE Common Slot Power Supplies
Product Series: 460W Platinum Hot-Plug Series
Product Type: Server Power Supply Unit (Hot-Plug / Redundant)
Product Name: HPE 460W Common Slot Platinum Power Supply

KEY FEATURES:
Power Output Capacity: 460 Watts
Input Voltage: 100–240V AC (Auto-ranging)
Input Frequency: 50/60 Hz
Input Current: 6A (100V) / 3A (240V)
Efficiency Rating: 80 PLUS Platinum Certified (up to 94% efficiency)
Hot-Plug Support: Yes
Redundancy Support: Supported (dual PSU configuration)
Cooling Type: Integrated variable-speed fan
Compatibility: HPE ProLiant G6, G7, Gen8 servers with Common Slot design

PERFORMANCE:
Output Power: 460W continuous
Voltage Rails: +12V DC main output
Power Factor Correction (PFC): Active
Protection Features: Over Voltage, Over Current, Over Temperature, and Short Circuit Protection

ENVIRONMENTAL & RELIABILITY:
Operating Temperature: 10°C to 50°C
MTBF: ~200,000 hours (approximate)
Reliability Rating: Enterprise-class, 24×7 continuous operation

PHYSICAL:
Form Factor: HPE Common Slot Hot-Plug
Typical Dimensions: Approx. 190 mm × 85 mm × 40 mm
Weight: ~1.0 kg (~2.2 lbs)
