46X0886 IBM 600GB 15000RPM SAS 6Gbps Hot Swap Hard Drive

46X0886 Specifications

IBM 600 GB 15,000 RPM SAS 6 Gb/s 3.5-inch Hot-Swap HDD

Manufacturer: IBM
Manufacturer Model: 46X0886
Product Line: IBM Enterprise SAS HDD
Product Series: 3.5-inch (Large Form Factor) SAS 15K
Product Type: Internal Hard Disk Drive (Hot-Swap)
Product Name: IBM 600 GB 15K SAS LFF HDD

KEY FEATURES:
Storage Capacity: 600 GB
Interface Type: SAS (6 Gb/s)
Rotational Speed: 15,000 RPM
Form Factor: 3.5-inch (Large Form Factor, LFF)
Hot-Swap Support: Yes — enterprise server/array compatible
Typical Cache (Buffer) Size: Enterprise-class (exact size not always publicly specified)

PERFORMANCE:
Maximum Interface Transfer Rate: 6 Gb/s (SAS)
Average Seek Time: Enterprise-class (approximate values ~4–5 ms)
Average Latency: ~2.0 ms (typical for 15K RPM)
Optimized for high-throughput, high-IOPS enterprise workloads

ENVIRONMENTAL & RELIABILITY:
Designed for 24×7 continuous enterprise storage operation
Reliability: Enterprise-grade, high MTBF (approximately 1.6 million hours as listed for similar models)
Shock, vibration, and endurance ratings: Duty-rated for enterprise usage (specific numerical values not always listed)

PHYSICAL:
Form Factor: 3.5-inch Large Form Factor (LFF) hot-swap drive
Typical Dimensions: Standard for 3.5-inch enterprise drives (approx. 146 mm × 101.6 mm × 25.4 mm)
Weight: Approx. ~0.8 kg
