WS-C2960CX-8TCL++ Cisco Catalyst 2960CX-8TC-L at discount

WS-C2960CX-8TCL++ Specifications

Cisco Catalyst 2960-CX 8-Port Data LAN Base Switch

Manufacturer: Cisco
Manufacturer Model: WS-C2960CX-8TCL++
Product Line: Cisco Catalyst 2960-CX Series
Product Series: 8-Port Data LAN Base (TAA compliant)
Product Type: Managed Network Switch
Product Name: Cisco Catalyst 2960-CX 8-Port Data LAN Base Switch

KEY FEATURES:
Ports: 8 × 10/100/1000 Mbps RJ-45 Gigabit Ethernet
Uplink Ports: 2 × 1G SFP + 2 × 1G copper uplink ports
Switching Capacity (full-duplex): ~24 Gbps
Forwarding Rate (64-byte packets): ~17.9 Mpps
Software Feature Set: LAN Base
Jumbo Frame Support: Up to ~9,000 bytes

PERFORMANCE:
Maximum Forwarding Rate: ~17.9 Mpps
Switching Capacity: ~12–24 Gbps (depending on direction)
Latency: Typical for compact access switch design (not explicitly specified)
Jumbo Frame Support: Up to ~9,000 bytes

ENVIRONMENTAL & RELIABILITY:
Operating Temperature Range: ~0 °C to +45 °C (32 °F to 113 °F)
Storage Temperature Range: ~-25 °C to +70 °C (-13 °F to 158 °F)
Operating Humidity: ~5% to 95% non-condensing
MTBF: ~441,000 hours

PHYSICAL:
Dimensions (W × D × H): ~10.6″ × 8.4″ × 1.7″ (~26.9 cm × 21.3 cm × 4.4 cm)
Weight: ~1.8 kg (4.0 lb)
Power Consumption (Operational): ~16.7 W
Input Voltage: AC 100-240 V, 50/60 Hz (autoranging internal PSU)
