PEX2IDE Specifications

StarTech 1‑Port PCI Express IDE Controller Adapter Card

Manufacturer: StarTech
Manufacturer Model: PEX2IDE
Product Line: StarTech IDE Expansion Cards
Product Series: PCIe to IDE Controller
Product Type: PCI Express IDE Adapter Card
Product Name: StarTech PCIe IDE Controller Adapter

KEY FEATURES:
Bus Interface: PCI Express x1 slot
IDE Port: 1 × Parallel ATA (IDE/PATA) connector (40‑pin)
Channels Supported: 2 channels (supports two IDE drives on one port)
IDE Modes Supported: PIO 0/1/2/3/4 and UDMA 33/66/100/133
LBA Support: 48‑bit Logical Block Addressing for drives over 137 GB
ATA/ATAPI Support: Yes (hard drives, optical drives, tape drives)
Bracket Type: Includes standard and low‑profile/half‑height brackets

PERFORMANCE:
Maximum Data Transfer Rate: Up to 133 MB/s (UDMA 6/ATA‑133)

ENVIRONMENTAL & RELIABILITY:
Operating Environment: Standard desktop/server environments
Certifications: RoHS, CE, FCC compliant
Warranty: Limited lifetime manufacturer warranty

PHYSICAL:
Form Factor: PCI Express plug‑in adapter card
Card Weight: ~120 g
Typical Package Dimensions: ~165 mm × ~230 mm × ~42 mm (packaged)

COMPATIBILITY:
Supported Operating Systems:
• Windows 2000, XP, Vista, 7, 8, 8.1, 10 (32/64‑bit)
• Windows Server 2003, 2008 R2, 2012, 2016
Legacy IDE Drives: Hard drives, CD/DVD drives, tape drives (ATA/ATAPI)
