ICX7150-24-4X1G Ruckus 7150-24 Switch 24 ports at discount

ICX7150‑24‑4X1G Specifications

Ruckus ICX7150 24‑Port Gigabit Access Switch with 4×1 GbE Uplink/Stacking

Manufacturer: Ruckus
Manufacturer Model: ICX7150‑24‑4X1G
Product Line: ICX 7150 Series
Product Series: 24‑Port Entry Access Switch
Product Type: Fixed‑configuration Access Switch
Product Name: Ruckus ICX7150 24‑Port Switch (4×1 GbE uplink)

KEY FEATURES:

24 × 10/100/1000 Mbps RJ‑45 access ports

2 × 1 GbE RJ‑45 uplink ports + 4 × 1 GbE SFP uplink/stacking ports (upgradable to up to 4×10 GbE SFP+ with license)

Stackable: Up to 12 switches per stack; aggregate stacking bandwidth ~480 Gbps

Switching capacity: ~132 Gbps maximum

Forwarding capacity (approx): ~98 Mpps

PERFORMANCE:

Switching Capacity (full‑duplex): ~132 Gbps

Forwarding Rate: ~98 Mpps

ENVIRONMENTAL & RELIABILITY:

Designed for enterprise access deployments, stack resiliency built‑in (stack failover, simplified management)

Operating in campus/branch environment; silent or fan‑quiet mode possible on some variants

PHYSICAL:

Form Factor: 1U rack‑mountable chassis

Typical Dimensions: Height ~1.7″ (≈43 mm) × Width ~17.3″ (≈439 mm) × Depth ~11″ (≈279 mm)

Weight: Not specified
