ASA5585-S60F60-K9 Cisco ASA 5585-X Firewall Appliance

ASA5585‑S60F60‑K9 Specifications

Cisco ASA 5585‑X Firewall Appliance with FirePOWER SSP‑60

Manufacturer: Cisco
Manufacturer Model: ASA5585‑S60F60‑K9
Product Line: Cisco ASA 5585‑X Series
Product Series: ASA 5585‑X
Product Type: Enterprise Network Security / Firewall Appliance
Product Name: Cisco ASA 5585‑X Firewall with SSP‑60 and FirePOWER SSP‑60

KEY FEATURES:
Form Factor: 2U rack‑mountable enterprise appliance
Security Services Processor: SSP‑60 and FirePOWER SSP‑60 integrated
Interfaces: 12 × Gigabit Ethernet ports
High‑Speed Interfaces: 8 × 10 Gigabit Ethernet SFP+
Expansion Slots: Up to 10 total (including SFP+ modules)
USB: Supported for console/management
Encryption: 3DES and AES support
High Availability: Dual AC power supplies (redundancy)
Security Contexts: High capacity (varies by license and configuration)

PERFORMANCE:
Firewall Throughput (maximum): ~20 Gbps
Concurrent Sessions: Up to ~10,000,000
IPsec VPN Throughput: ~4.5 Gbps
SSL VPN Throughput: ~3 Gbps
Maximum VPN Peers: ~10,000
New Connections per Second: ~350,000
Application Control (AVC) / IPS Throughput (approximate): mid‑range high performance
Supported Applications & Services: URL filtering, anti‑malware, IPS, and advanced threat protection

ENVIRONMENTAL & RELIABILITY:
Operating Temperature Range: Typical enterprise standard (0 °C to ~40 °C)
Operating Humidity: Enterprise standard non‑condensing range
Power: Dual hot‑swappable AC power supplies

PHYSICAL:
Dimensions (H × W × D): ~3.5 × 17.5 × 21.8 inches (~8.8 × 44.5 × 55.4 cm)
Weight: ~35 lbs (~15.9 kg)
Memory (RAM): ~24 GB
Flash Storage: ~2–8 GB range (varies by configuration)
Form Factor: 2U rack mount
