700513916 Avaya J139 IP Phone

700513916 Specifications

Avaya J139 IP Phone

Manufacturer: Avaya
Manufacturer Model: 700513916
Product Line: Avaya J100 Series
Product Series: J139
Product Type: IP Desk Phone (SIP)
Product Name: Avaya J139 IP Phone

KEY FEATURES:
Display: 2.8″ color display (320 × 240 pixels)
Line/Feature Keys: 4 dual‑colour (red/green) line/feature LEDs
Soft Keys: 4 context‑sensitive soft keys
Audio: Wideband audio in handset and wired headset; full‑duplex speakerphone
Headset Support: RJ‑9 headset port with Electronic Hook Switch (EHS) support; built‑in volume‑boost for hearing‑impaired
Network / Power: Dual Gigabit Ethernet ports (10/100/1000 Mbps) including PC pass‑through; Power over Ethernet (IEEE 802.3af Class 1) with support for energy‑efficient Ethernet (802.3az)
Protocol Support & Compatibility: SIP (supports SIP‑AST for enhanced features and integration with Avaya Aura® and Avaya IP Office™)
Expandability: Supports up to three JBM24 expansion modules
Positioning / Use Case: Entry‑level IP phone suited for users who need color display, basic headset support, and Gigabit connectivity

PERFORMANCE:
Supported Codecs: G.711 a/µ, G.726, G.729AB, G.722, Opus
Call Log / Directory: Recent call log up to ~100 entries; Avaya Aura contact list up to ~250 entries
Power Efficiency: PoE Class 1 design with “sleep mode” capability

ENVIRONMENTAL & RELIABILITY:
Operating Temperature Range: 0 °C to 40 °C (32 °F to 104 °F)
Storage / Non‑Operating Temperature Range: ‑20 °C to 60 °C (‑4 °F to 140 °F)
Operating Humidity: 10% to 95% non‑condensing
Reliability: Enterprise‑grade build with hearing‑aid compatible handset and full‑duplex speakerphone

PHYSICAL:
Dimensions (H × W × D): ~170 × 155 × 71 mm (~6.7″ × 6.1″ × 2.8″)
Weight: ~0.68 kg (~1.5 lb)
Color / Finish: Charcoal (Dark Grey) finish
